  2. Thickness/Thin Grader

It has been developed for the grading of rice according to thickness/width. It can easily separate chalky, red, fine broken rice, and impurities that are bigger than the screen slots.

The Thickness/Width Grader consists of one rotating, cylindrical screen, made of metal sheet where the rice is separated according to size.

Working Principle:

  1. Based on the ratio of Over-size and Under-size rice grains at input, the cylinder configuration is decided.
  2. Rice is gradually fed into the cylinder rotation at constant speed.
  3. The defined gap in the wire mesh type cylinder allows the rice grain smaller than gap to fall through & discharged through the outlet at bottom.
  4. Over-size rice grains travel through the interior of cylinder are discharged on the side through a specific outlet.

Suitable for:

Paddy - Non-Basmati - Short, Medium & Long Grains

Paddy - Basmati ◦ Raw ◦ Steamed ◦ Parboiled Boiled

Construction

  • Mild Steel laser cut structure with bolted Construction.
  • Stainless Steel wire mesh cylinder with PU Rims for smooth operation..
  • Hardened Articulating wedge and base.

Salient features

  1. Wire Mesh type cylinder with uniform and precise gapping for efficient segregation.
  2. Exclusive cleaning system for the separation screens through Brush rollers.
  3. Machine structure made of steel sheet including upper and side covers for safety operation.
  4. Separation cylinder mounted in the horizontal position.
  5. Single Motor drive for low power consumption.
